SRV225
MODE SRV225 TYPE Single-cylinder 4-stroke, forced air cooling, OHV, vertical shaft CYLINDER BORE ×STROKE(mm) 70*58 DISPLACEMENT(ml) 223 RATED POWER[kw-（r/min）] 4.4/3600 MAXIMUM NET TORQUE 12.2/2800 FUEL CAPACITY(L) 1.2 ROTATE DIRECTION Counterclockwise (facing the output shaft) STARTING SYSTEM Kick start/Electric start L×W×H(mm) 398×332×275 NET WEIGHT(kg) 10.5(13)
SRV200
MODE SRV200 TYPE Single-cylinder 4-stroke, forced air cooling, OHV, vertical shaft CYLINDER BORE ×STROKE(mm) 70*52 DISPLACEMENT(ml) 200 RATED POWER[kw-（r/min）] 4/3600 MAXIMUM NET TORQUE 11.5/2800 FUEL CAPACITY(L) 1.2 ROTATE DIRECTION Counterclockwise (facing the output shaft) STARTING SYSTEM Kick start/Electric start L×W×H(mm) 398×332×275 NET WEIGHT(kg) 10.5(13)
SRV180
MODE SRV180 TYPE Single-cylinder 4-stroke, forced air cooling, OHV, vertical shaft CYLINDER BORE ×STROKE(mm) 70*47 DISPLACEMENT(ml) 180 RATED POWER[kw-（r/min）] 3.5/3600 MAXIMUM NET TORQUE 9.8/2800 FUEL CAPACITY(L) 1 ROTATE DIRECTION Counterclockwise (facing the output shaft) STARTING SYSTEM Kick start/Electric start L×W×H(mm) 331×307×245 NET WEIGHT(kg) 8.5(10.5)
SRV150
MODE SRV150 TYPE Single-cylinder 4-stroke, forced air cooling, OHV, vertical shaft CYLINDER BORE ×STROKE(mm) 65*45 DISPLACEMENT(ml) 149 RATED POWER[kw-（r/min）] 2.6/3600 MAXIMUM NET TORQUE 8/2800 FUEL CAPACITY(L) 1 ROTATE DIRECTION Counterclockwise (facing the output shaft) STARTING SYSTEM Kick start/Electric start L×W×H(mm) 331×307×245 NET WEIGHT(kg) 8.5（10.5）
SRV130
MODE SRV130 TYPE Single-cylinder 4-stroke, forced air cooling, OHV, vertical shaft CYLINDER BORE ×STROKE(mm) 61*45 DISPLACEMENT(ml) 131 RATED POWER[kw-（r/min）] 2.4/3600 MAXIMUM NET TORQUE 7/2800 FUEL CAPACITY(L) 1 ROTATE DIRECTION Counterclockwise (facing the output shaft) STARTING SYSTEM Hand start L×W×H(mm) 331×307×245 NET WEIGHT(kg) 8.5
