Output[ kw-(r/min)]2.4/3600
-
Overall Dimensions( mm )331×307×245
-
Weight ( kg )8.5
Panel Information
Features
Easy Start: Quick and reliable ignition ensures you spend less time starting and more time working.
Low Vibration: Professional balance technology reduces vibration for smoother operation and less operator fatigue.
Lightweight Design: Easy to carry and maneuver, perfect for extended use without strain.
Durable Engine: Cylinder liner construction enhances wear resistance, significantly extending engine life.
Heavy-Duty Filtration: Large-capacity air filter provides superior protection against dust and debris.
Automatic Choke: Smart choke mechanism automatically adjusts for easy starting in cold or hot conditions.
Usage Scenarios
Parameter Table
| MODE | SRV130 |
| TYPE | Single-cylinder 4-stroke, forced air cooling, OHV, vertical shaft |
| CYLINDER BORE ×STROKE(mm) | 61*45 |
| DISPLACEMENT(ml) | 131 |
| RATED POWER[kw-(r/min)] | 2.4/3600 |
| MAXIMUM NET TORQUE | 7/2800 |
| FUEL CAPACITY(L) | 1 |
| ROTATE DIRECTION | Counterclockwise (facing the output shaft) |
| STARTING SYSTEM | Hand start |
| L×W×H(mm) | 331×307×245 |
| NET WEIGHT(kg) | 8.5 |
