SR500
MODE SR500 TYPE Single-cylinder 4-stroke, forced air-cooled, OHV, horizontal shaft, 25° tilt CYLINDER BORE ×STROKE(mm) 94×72 DISPLACEMENT(ml) 500 RATED POWER[kw-(r/min)] 12.5/3600 MAXIMUM NET TORQUE 35/2800 FUEL CAPACITY(L) 7 ROTATE DIRECTION Counterclockwise (facing the output shaft) STARTING SYSTEM Kick start/Electric start L×W×H（mm） 490×350×445 NET WEIGHT(kg) 32.5（35.5）
SR460
MODE SR460 TYPE Single-cylinder 4-stroke, forced air-cooled, OHV, horizontal shaft, 25° tilt CYLINDER BORE ×STROKE(mm) 92×69 DISPLACEMENT(ml) 458 RATED POWER[kw-(r/min)] 10/3600 MAXIMUM NET TORQUE 30/2500 FUEL CAPACITY(L) 6.5 ROTATE DIRECTION Counterclockwise (facing the output shaft) STARTING SYSTEM Kick start/Electric start L×W×H（mm） 450×405×445 NET WEIGHT(kg) 32(35)
SR445
MODE SR445 TYPE Single-cylinder 4-stroke, forced air-cooled, OHV, horizontal shaft, 25° tilt CYLINDER BORE ×STROKE(mm) 92×67 DISPLACEMENT(ml) 445 RATED POWER[kw-(r/min)] 9.0/3600 MAXIMUM NET TORQUE 26/2500 FUEL CAPACITY(L) 6.5 ROTATE DIRECTION Counterclockwise (facing the output shaft) STARTING SYSTEM Kick start/Electric start L×W×H（mm） 450×405×445 NET WEIGHT(kg) 31(34)
SR420
MODE SR420 TYPE Single-cylinder 4-stroke, forced air-cooled, OHV, horizontal shaft, 25° tilt CYLINDER BORE ×STROKE(mm) 90×66 DISPLACEMENT(ml) 420 RATED POWER[kw-(r/min)] 8.2/3600 MAXIMUM NET TORQUE 23/2500 FUEL CAPACITY(L) 6.5 ROTATE DIRECTION Counterclockwise (facing the output shaft) STARTING SYSTEM Kick start/Electric start L×W×H（mm） 450×405×445 NET WEIGHT(kg) 31(34)
SR390
MODE SR390 TYPE Single-cylinder 4-stroke, forced air-cooled, OHV, horizontal shaft, 25° tilt CYLINDER BORE ×STROKE(mm) 88×64 DISPLACEMENT(ml) 389 RATED POWER[kw-(r/min)] 7.5/3600 MAXIMUM NET TORQUE 21/2500 FUEL CAPACITY(L) 6.5 ROTATE DIRECTION Counterclockwise (facing the output shaft) STARTING SYSTEM Kick start/Electric start L×W×H（mm） 450×405×445 NET WEIGHT(kg) 31(34)
SR270
MODE SR270 TYPE Single-cylinder 4-stroke, forced air-cooled, OHV, horizontal shaft, 25° tilt CYLINDER BORE ×STROKE(mm) 77×58 DISPLACEMENT(ml) 270 RATED POWER[kw-(r/min)] 5.6/3600 MAXIMUM NET TORQUE 16/2500 FUEL CAPACITY(L) 6.5 ROTATE DIRECTION Counterclockwise (facing the output shaft) STARTING SYSTEM Kick start/Electric start L×W×H（mm） 430×380×410 NET WEIGHT(kg) 25(28)
SR225
MODE SR225 TYPE Single-cylinder 4-stroke, forced air-cooled, OHV, horizontal shaft, 25° tilt CYLINDER BORE ×STROKE(mm) 70×58 DISPLACEMENT(ml) 223 RATED POWER[kw-(r/min)] 4.5/3600 MAXIMUM NET TORQUE 13/2500 FUEL CAPACITY(L) 3.6 ROTATE DIRECTION Counterclockwise (facing the output shaft) STARTING SYSTEM Kick start/Electric start L×W×H（mm） 370×320×330 NET WEIGHT(kg) 16(18)
SR210
MODE SR210 TYPE Single-cylinder 4-stroke, forced air-cooled, OHV, horizontal shaft, 25° tilt CYLINDER BORE ×STROKE(mm) 70×55 DISPLACEMENT(ml) 212 RATED POWER[kw-(r/min)] 4.2/3600 MAXIMUM NET TORQUE 12/2500 FUEL CAPACITY(L) 3.6 ROTATE DIRECTION Counterclockwise (facing the output shaft) STARTING SYSTEM Kick start/Electric start L×W×H（mm） 370×320×330 NET WEIGHT(kg) 16(18)
SR200
MODE SR200 TYPE Single-cylinder 4-stroke, forced air-cooled, OHV, horizontal shaft, 25° tilt CYLINDER BORE ×STROKE(mm) 68×54 DISPLACEMENT(ml) 196 RATED POWER[kw-（r/min）] 3.6/3600 MAXIMUM NET TORQUE 10/2500 FUEL CAPACITY(L) 3.6 ROTATE DIRECTION Counterclockwise (facing the output shaft) STARTING SYSTEM Kick start/Electric start L×W×H(mm) 370×320×330 NET WEIGHT(kg) 16(18)
SR100
MODE SR100 TYPE Single-cylinder 4-stroke, forced air-cooled, OHV, horizontal shaft, 25° tilt CYLINDER BORE ×STROKE(mm) 56×40 DISPLACEMENT(ml) 98 RATED POWER[kw-（r/min）] 1.5/3600 MAXIMUM NET TORQUE 5/2500 FUEL CAPACITY(L) 1.6 ROTATE DIRECTION Counterclockwise (facing the output shaft) STARTING SYSTEM Kick start/Electric start L×W×H(mm) 325×240×330 NET WEIGHT(kg) 11（12）
SR80
MODE SR80 TYPE Single-cylinder 4-stroke, forced air-cooled, SV, horizontal shaft CYLINDER BORE ×STROKE(mm) 54×46 DISPLACEMENT(ml) 105 RATED POWER[kw-（r/min）] 1.1/3600 MAXIMUM NET TORQUE 3.5/2500 FUEL CAPACITY(L) 1.5 ROTATE DIRECTION Counterclockwise (facing the output shaft) STARTING SYSTEM Hand start L×W×H(mm) 270×265×345 NET WEIGHT(kg) 9
