Dimensions & Performance
|
|
Overall Dimensions
|
1,830 × 1,286 × 755 mm (72 × 51 × 30 in)
|
|
Machine Weight
|
302 kg (666 lb)
|
|
Cutting Width
|
1,220 mm (48 in)
|
|
Cutting Height
|
25–105 mm (1–4 in)
|
|
Height Adjustment
|
Electric, continuously adjustable
|
|
Cutting System
|
3-blade rotary cutting system
|
|
Blade Type
|
Straight Blade
|
|
Blade Motor Speed
|
3,000 RPM
|
|
Mowing Productivity
|
5,000–10,000 m²/h (1.25–2.5 acres/h)*
|
|
Max. Mowing Speed
|
8 km/h (5 mph)
|
|
Max. Travel Speed
|
12.8 km/h (8 mph)
|
|
Max. Working Slope
|
20°
|
|
Water Resistance
|
IPX5
|
|
Battery & Charging
|
|
Battery Chemistry
|
LFP
|
|
Maximum Battery Capacity
|
9 kWh
|
|
Battery Configuration
|
1–6 modular battery packs
|
|
Runtime
|
Approx. 4–5 h*
|
|
Charging Voltage
|
120V/220V
|
|
Fast Charging Time
|
Approx. 4.5 h
|
|
Standard Charging Time
|
Approx. 9 h
|
|
Autonomous & Intelligent Functions
|
|
Positioning
|
RTK / nRTK + LiDAR + IMU
|
|
Obstacle Detection
|
LiDAR + Vision + Ultrasonic
|
|
Virtual Boundary
|
Yes
|
|
Automatic Route Planning
|
Yes
|
|
Multi-Zone Management
|
Yes
|
|
Map Storage
|
Yes
|
|
Multi-Mower Map Sharing
|
Yes
|
|
Remote Operation
|
Yes
|
|
Tilt Detection
|
Yes
|
|
Rain Sensor
|
Yes
|
|
OTA Updates
|
Yes
|
